Game preset
Assetto Corsa Competizione: controller layout for Mac
Assetto Corsa Competizione does not need a controller-aware version of itself to be played from a controller on a Mac. InputConfig sends real keyboard and mouse events, so the game sees a keyboard and a mouse, and you hold the controller. This is the layout the app's Smart Preset Maker builds for it: GT endurance racing simulator.
Get the preset in two clicks
- Open InputConfig and click Smart Preset Maker on the welcome screen.
- Search for Assetto Corsa Competizione and pick it. The layout below is created as a preset in your sidebar, named and ready.
- Press Activate. Every row can be changed afterwards: the editor's Scan button rebinds any control the moment you touch it.
The preset can open the game for you when it activates: it launches steam://run/805550 on activate, and confines and hides the pointer while it runs, so a stray mouse never leaves the window.
The full button map
| Controller | Sends | What it does |
|---|---|---|
| Left stick left | , | Left stick left steers left (comma) |
| Left stick right | . | Left stick right steers right (period) |
| Right trigger | A | Right trigger is the throttle (A) |
| Left trigger | Z | Left trigger is the brake (Z) |
| RB / R1 | Space | RB shifts up a gear (Space) |
| LB / L1 | Alt / Option (Left) | LB shifts down a gear (Left Alt) |
| A / Cross | S | A engages the starter motor (S) |
| B / Circle | L | B cycles the car light stages (L) |
| X / Square | Shift (Left), L | X flashes the high beams (Shift + L) |
| Y / Triangle | Ctrl (Left), L | Y toggles the rain lights (Ctrl + L) |
| L3 (left stick click) | Alt / Option (Left), L | L3 engages the pit limiter (Alt + L) |
| R3 (right stick click) | Shift (Left), I | R3 runs the ignition sequence (Shift + I) |
| Back / Share / Select | F | Back cycles the cockpit display pages (F) |
| Start / Options | Escape | Start pauses to the race menu (Esc) |
| D-pad left | Mouse motion left (speed 16) | D-pad left glances left in the cockpit |
| D-pad right | Mouse motion right (speed 16) | D-pad right glances right in the cockpit |
| D-pad up | F2 | D-pad up changes the camera view (F2) |
| D-pad down | F1 | D-pad down opens the HUD page (F1) |
| Right stick left | Mouse motion left (speed 18) | Right stick looks left around the cockpit |
| Right stick right | Mouse motion right (speed 18) | Right stick looks right around the cockpit |
| Right stick up | Mouse motion up (speed 18) | Right stick looks up around the cockpit |
| Right stick down | Mouse motion down (speed 18) | Right stick looks down around the cockpit |
Button names follow the Xbox / PlayStation pair shown in the editor, so A / Cross is the bottom face button on either pad. On a Switch Pro Controller the bottom button is labelled B; the mapping still fires on position.
Tips
- ACC uses comma and period for keyboard steering, so the left stick maps to those keys; for real wheel feel ACC still works best with a wheel and pedals.
- Shift up sits on RB at Space and shift down on LB at Left Alt, matching the sim's sequential keyboard shifting.
Make it yours
Nothing here is fixed. Rows can be re-scanned to a different control, given hold and double-tap actions, chords, turbo, macros, haptic or spoken feedback, and per-binding deadzones and sensitivity curves. The binding editor guide covers every option, and the controller map shows what each control is called.
